| No | Feature |
|---|---|
| 1 | 8 channels, support SPST (Single Path Single Throw). |
| 2 | Switching Load 8A/250VAC、5A/30VDC. |
| 3 | Action Time: 10ms (typical). |
| 4 | Dielectric Strength: coil-contact 4000V AC. |
| 5 | Contact Resistance: 100mΩ. |
| 6 | Mechanical life up to 10^7 times. |
| 7 | Single module with single slot, applicable to NXI-F1000 chassis or independent use. |
| 8 | Support 12V DC power supply input, LAN communication for individual control. |
| 9 | Support Modbus-RTU, SCPI protocols. |
