The CobaltFx FET-WR10-HP is the high-power version of the WR-10 frequency extension module, enabling W-band (75–110 GHz) measurements requiring higher output power. It supports demanding applications including amplifier evaluation, waveguide component characterization, and mmWave research. Integrated into the CobaltFx architecture, it provides a scalable and flexible mmWave test solution.
Key capabilities and advantages
Technical specifications and parameters
| Frequency Range | 75 GHz – 110 GHz |
| Connector Type | Waveguide WR-10 |
| Attenuator Range | 0 – 30 dB |
| Dynamic Range | Up to ~120 dB typical (10 Hz IF BW) |
| Test-Port Output Power | High-power configuration (varies by module) |
| Multiplication Factor | Per product datasheet |
| Waveguide Interface | Proxi-Flange™ |
| Operating Temperature | 0 °C to +50 °C (spec +20 °C to +30 °C) |
